8INCH Face Recognition Thermometer Gel Soap dispenser
MG-08D
Vertical temperature measurement face recognition access management module
Product introduction:
MG-08D vertical temperature measurement face recognition access management module, using Rockchip RK3288 / RK3399 / Qualcomm MSM8953 high performance hardware platform, equipped with industrial binocular camera and face biometric technology, as well as infrared thermal imaging module, support Mask recognition. It also supports expansion of various peripherals such as ID card readers, fingerprint readers, etc., which can be applied to gate passages and access control attendance to achieve safe and efficient access control for personnel.
Application:
Can be used with access gates and access control for communities, office buildings, schools, hotels, scenic spots, transportation hubs and other public service places.
Feature
1. Adopt 8-inch IPS full-view LCD display face recognition gel dispenser thermormeter
2. Industrial-grade appearance, waterproof and dustproof design, stable and reliable.
3. Support 3W face database. The 1: 1 comparison recognition rate is more than 99.7%, the 1: N comparison recognition rate is more than 96.7% 0.1% misrecognition rate, and the live detection accuracy rate is 98.3% 1% misrejection rate. Face recognition pass speed is less than 1 second.
4. Supports accurate face recognition and comparison while wearing a mask.
5, using industrial-grade binocular wide dynamic camera, infrared and LED double compensation at night.
6. Support optional Rockchip RK3288 quad-core processor, Rockchip RK3399 six-core processor and Qualcomm MSM8953 octa-core processor.
7. Support human body temperature detection, temperature display, 1-meter ultra-long body temperature detection, 0.2 ℃ error, support and automatic alarm for abnormal body temperature, second-level detection speed, and real-time export of attendance temperature measurement data.
8, support for ID card reader, fingerprint reader, IC card reader, two-dimensional code reader and other peripheral expansion.
9. Support system-level, APP offline-level, APP + background network-level API docking, complete documentation, and support secondary development.
Technical Parameters
Model
MG-08D
Camera
Screen
Processor
Parts
Interface
Resolution
200W pixel
Type
Binocular wide dynamic camera
Focusing distance
50~150cm
White balance
automatic
Size
8.0inch IPS LCD
Resolution
800*1280
CPU
RK3288 Quad core /RK3399 six core /MSM8953 eight core
Memory
EMMC 8G
Fill light
LED and Infrared double fill light
Network module
Supports Ethernet,wireless(WIFI)
Audio
Support 2.5W/4R speaker
USB port
1 road USB OTG,1 road USB HOST standard A port
Serial communication interface
1 road RS232 Serial port
Function
Relay output
1 door open signal output
Wiegand interface
One Wiegand 26/34 output, one Wiegand 26/34 input
Upgrade button
Support Uboot upgrade button
Wired network interface
1 RJ45 Ethernet socket
Face Detection
Supports detection and tracking of multiple people at the same time
Face library support
Up to 30,000
1: N face recognition
Support
1: 1 face comparison
Support
Stranger detection
Support
Identify distance configuration
Support
UI interface configuration
Support
Remote device upgrade
Support
Device interface
Interfaces include device management, personnel / photo management, record query, etc.
Deployment method
Support public cloud deployment, privatized deployment, LAN use, stand-alone use
Infrared thermal imaging module
Human temperature detection
Support
Temperature detection distance
1 Meter
Temperature measurement accuracy
