Digital handheld galvanized Paint depth Gauge Galvanizing Thickness Measurement
Digital handheld galvanized Paint depth Gauge Galvanizing Thickness Measurement 1
Digital handheld galvanized Paint depth Gauge Galvanizing Thickness Measurement 2

Digital handheld galvanized Paint depth Gauge Galvanizing Thickness Measurement

0.00 / 5 (0 user)
SKU: SHP-5C208448DA858313
Brand: Unbranded
Category: Varied
$445.15 $893.95
Brand / Provider Unbranded
Store Onvels
Product type ONVELS checkout
ONVELS commerce profile This offer is prepared for multiple selling flows.
External offer Prepared Digital delivery Prepared
default
default

Product Description Measuring Range 0-1500µm (0-1.5mm) or 0-60mil Resolution 0.1µm (0-99.9 µm) and 1µm (over 100 µm) Color Blue ,Black ,Red ,Yellow Application measuring coating thickness Accuracy ±1-2% (±2.5µm or 0.1mil - whichever the greater) Certifica

Product Description
Measuring Range
0-1500µm (0-1.5mm) or 0-60mil
Resolution
0.1µm (0-99.9 µm) and 1µm (over 100 µm)
Color
Blue ,Black ,Red ,Yellow
Application
measuring coating thickness
Accuracy
±1-2% (±2.5µm or 0.1mil - whichever the greater)
Certification
CE, RoHS
Power supply
2 x 1.5V AA Batteries
Warranty
1 years
Item Name
coating thickness gauge
Minimum Measurement Area
5mm
Minimum Sample Thickness
0.3mm
MOQ
1 Piece
Model Number
GTS820F
Operating Conditions
Temp: -10 - 50ºC and Humidity: < 85%
Weight
97g ( including batteries)
Dimensions
126 x 69 x 35mm
Features
1.Thickness measurement using Magnetic Method to measure the non-magnetic coating on a magnetic metal substrate.
2.Single-point or two-point method could be used to correct probe system deviation, in order to ensure the accuracy of the device in the process of measuring.
3.Power voltage indicator.supply by USB 5V or 2 AA batteries (AA)
4.Speaker beep while operating.
5.Power-off automatically when idle; manually power-off available.
6.Negative display function to ensure the accuracy of zero point calibration.
7.Ultra-low power consumption, less than 10 μA in standby mode.
8.Operation method: Graphic menu button operation
9.Human-computer interaction: buttons, backlight dot matrix screen, light, buzzer
10.Data transfer: USB, Bluetooth
11.PC software: Windows PC, Android App , iOS App
