Farm machine 350L Tractor Rear Agricultural Mist Sprayer
Farm machine 350L Tractor Rear Agricultural Mist Sprayer 1
Farm machine 350L Tractor Rear Agricultural Mist Sprayer 2

Farm machine 350L Tractor Rear Agricultural Mist Sprayer

0.00 / 5 (0 user)
SKU: SHP-3699CED9F5865746
Brand: Unbranded
Category: Varied
$2862.72 $5802.72
Brand / Provider Unbranded
Store Onvels
Product type ONVELS checkout
ONVELS commerce profile This offer is prepared for multiple selling flows.
External offer Prepared Product label Prepared

Product Description Tractor vehicle sprayer for agricultural farm Power Tank Sales Wide spray range, high operating efficiency, saving time and effort. Equipped with high-end combination valve, it integrates pressure regulation, reversing, segmented contr

Product Description
Tractor vehicle sprayer for agricultural farm Power Tank Sales
Wide spray range, high operating efficiency, saving time and effort. Equipped with high-end combination valve, it integrates pressure regulation, reversing, segmented control, filtration, pressure display as one, easy and fast to use. The machine is a three-point suspension with hydraulic automatic lifting and folding spraying machine. Its advantages are:
1. Wide spray range and high operating efficiency 2. The boom is lifted and folded, saving time and effort 3. Equipped with high-end combination valve, which integrates pressure regulation, reversing, segmented control, filtration, pressure display as one, easy and fast to use 4. Four-stage filtration without clogging the nozzle 5. High configuration and reliable performance 6. High atomization uniformity 7. The mixing system adopts a two-way configuration of reflux and high-pressure stirring, which can fully ensure the uniformity of the liquid medicine, which makes the pest control and disease prevention effect good. 8. Boom sprayer is suitable for hilly land operations. The spring shock absorber and the four-link pendulum-type rebalance mechanism can further eliminate the impact caused by uneven ground and make the spraying machine have high balance stability.
Specification
Main technical parameters of vehicle-mounted sprayer:
Main technical parameters of vehicle-mounted sprayer:
Supporting power (kW)
Tractors above 20 horsepower (users own matching)
Working width (m)
6-8 meters 5 sections folding (can be customized)
Medicine box capacity (L)
350
Liquid pump form
High pressure pump / diaphragm pump
Boom working pressure
0.2-0.4Mpa
Pump speed
900-1400r/min
Working pressure
1.5-3.5Mpa
Rated flow
34-52L/min
Nozzle number
14-16 (can be installed according to actual situation)
Pump flow (L / min)
40
Spray volume
At 0.3 MPa, 1.18 l / min (single), 500 mm apart
Nozzle form
Imported fan-shaped nozzle (fog cone angle 110 degrees)
Anti-drip device
Yes
Three-stage filtration
Liquid back stirring
Boom spray
6m-10m
Material
Steel pipe, PVC high-pressure nozzle (each nozzle can be opened and closed separately)
Dimensions
1495 * 1170 * 1540mm (transport status)
Anti-drip nozzle angle
Fan shape 110 degrees (adjustable)
Air supply car sprayer
