8MP 4K Feature
Supporting Face detection, Humanoid detectionn, and supports customization of other smart functions;
8.0MP HD Black light illumination resolution, clear and fine images;
Support 2D/3D noise reduction, digital wide dynamic;
Advanced H.265(Compatible with H.264) video compression, Super low rate, high definition quality of image;
Professional anti-lightning, conform to GB/T17626.5 and IEC61000-4-5;
Support ON VIF, access third party;
Support various mobile monitoring(iPhone, Android);
Product Description
Features:
1. H.265/H.264,support dual-stream,AVI;0.1M~8Mpbs variable;1~30f/s variable;
2. Color 0.1Lux;  B/W 0.01Lux;
3. 1 RJ45 Ethernet interface, 10/100M automatically adapting;
4. Support RTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPnP etc network protocol;
5. Support ON VIF, and mobile monitoring;
7. Metal case.
Specifications:

GS-GFS1CMA-POE / GS-GFS1CA3M-POE  / GS-GFS1CA4M-POE / GS-GFS1CA5M-POE   GS-GFS1CA8M-POE
System structure
Embedded RTOS,dual-core 32bit DSP,pure hard compression ,watch dog
Sensor
2MP:1/3"  CMOS sensor color 0.01Lux’F1.2,black/white 0.01Lux’F1.2
3MP:1/2.7" SC2235 CMOS sensor color 0.1Lux’F1.2,black/white 0.01Lux’F1.2
4MP:1/2.7" SC5239 CMOS sensor color 0.1Lux’F1.2,black/white 0.01Lux’F1.2
5MP:1/2.8"  CMOS sensor color 0.1Lux’F1.2,black/white 0.01Lux’F1.2
8MP:1/2.7 SC8239 Cmos senor  cloor 0.1lux F1.2 black and white 0.01lux F1.2
Video compression
H.265/H.264,support dual stream,AVI;0.1M~6Mpbs variable;1~30f/s variable
Image output
2MP:Main stream:1920*1080(25fps),
3MP:Mail stream:2048*1536(20fps),
4MP:Mail stream:2560*1440(20fps),
5MP:Mail stream:2592*1944(15fps),
8mp:Main Stream:3840*2160p(15fps)
Noise reduction
Support 2D/3D
lens
3.6MM MP lens Default,(2.8mm.6mm optional)
Storage
Via PC/Mobile Phone/NVR With HDD
Light
10pcs 940nm ir leds
Wide dynamic
Support digital
Network interface
1*RJ45 10/100M adaptive Ethernet port;support RTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPnP etc
Singal interface
One photo resistance interface,one IR-CUT interface ,support photo resistance signal and IR-CUT links to IR
AUDIO
Build inside mic
SD Card
NO
Reliability
Comprehensive lightning protection, in line with national and international standards; 7 * 24 hours 65’C  high temperature stable and reliable testing (including mounted machine testing)
Other function
NO
ON VIF
Support
Mobile monitoring
Support multiple mobile monitoring(iOS,Android)
Power
DC12V
Dimension
/
Housing material
Metal Housing

8MP Chipset Specification as below:



(Does not include Power Adapter)
Note: " 12V" Please use  12 V 1A power supply, packaging does not include the power supply. if you need ,pls send us message !
We recommend using our h.265 NVR, other manufacturers of NVR may not be able to run h.265 perfectly, it will run with h.264.

 Q & A
1, IP camera default IP address:192.168.1.10
User name:admin,password:empty(null)
If there is a problem with "Can not find the Device", it is the default ip address is not in the same network segment as your router.
Please click "Edit Device" to change the camera's ip address,
For example, if your router's ip address is 192.168.0.1, then you need to change the camera's ip address to 192.168.0.XX.
"DeviceManage" It can find and change the IP address, upgrade the firmware.

2, P2P website: "www.xmeye.net" ,please use IE and install ActiveX,only IE supports Multi Language.Chrome,Safari just support Chinese .
then please input your P2P ID,user name and password to login and preview.
Access to the IPC through the web, only one screen can be displayed.
There are multiple IPC, please use client software to manage(such as: CMS VMS SNVR)

3,The camera's port information.
on vif 2.0 Port 8899 ;RTSP Port 554 ;HTTP Port 80;Media Port 34567;E-mail default port  25; SLL protocol Port 465.
4,Does the cameras can be compatible with other manufacturers NVR?
Please confirm whether other manufacturers NVR support on vif protocol.
Our camera's on vif protocol is on vif Profile S, does not support HTTPS protocol;
Auto focus camera, other manufacturers NVR can only zoom, can not focus.

5, The camera all supports Motion Detect,FTP,Email alarm, RTSP.
A,How to set up motion detection?
Access to IPC via IE (or CMS software), device configuration - alarm function - motion detection - on and save.
B, About FTP
FTP upload video and pictures, pictures will always upload, video files larger, after the alarm, the video file will be completed to upload.
We suggest the Sever-U and FileZilla FTP Server to upload the video or image.
C,For the Email alarm,please use Email server which supports SMTP ( Hotmail ,Yahoo not support SMTP ,it not supports Gmail temperately since the server problem ) .
D, RTSP URL for VLC media Player :
RTSP port: 554
rtsp: // (IP): (PORT) / user = (USER) & password = (PWD) & channel = (Channel) & stream = (Stream) .sdp? Real_stream
Example:
rtsp: //10.6.10.25: 554 / user = admin & password = & channel = 1 & stream = 0.sdp? Real_stream (stream = 0 primary stream 1 auxiliary stream)
     If it is through the public network need to RTSP port open (default is 554), the port in the network service-RTSP can be set
6, About DDNS
Mapped media TCP port: 34567 and HTTP port: 80 (Note: mapping need to be changed to non-80)
Note: The two ports in the network settings can be viewed, can be modified
What domain names are supported?
- CN99 / DynDns / Oray / NO-IP / MYQ-SEE
7.
Q:When I finish the steps to add the camera to the CMS list,why it notify “ Can’t find the Device “  even I can see the default ip address 192.168.1.10 in the menu .
F: It is the IP Address conflict ,the default ip address is not in the same network segment as your router.
Please click “Edit Device “ to change the camera’s ip address to make them in the same network segment !
For example ,if your router’s ip address is 192.168.0.1 ,then you need to change the camera’s ip address to 192.168.0.XX .

Package contents:
1 x Camera,1 x English User Manual,1x Bracket
Note:
Software will be sent to your emails !pls contact with our SALES team if you need !


Note: If you need POE power supply, select the ADD POE option. If you do not select POE power supply, it is normal cable

Advanced H.265 Video Compression
Working With NVR For 24/7 Reliable Recording
