Handheld Heater Machine Quenching Welding Equipment Forging Soldering High Frequency Induction Heating Machine
Handheld Heater Machine Quenching Welding Equipment Forging Soldering High Frequency Induction Heating Machine 1
Handheld Heater Machine Quenching Welding Equipment Forging Soldering High Frequency Induction Heating Machine 2

Handheld Heater Machine Quenching Welding Equipment Forging Soldering High Frequency Induction Heating Machine

0.00 / 5 (0 user)
SKU: SHP-39629BF8EB6273A7
Brand: Unbranded
Category: Varied
$3860.00 $10700.00
Brand / Provider Unbranded
Store Onvels
Product type ONVELS checkout
ONVELS commerce profile This offer is prepared for multiple selling flows.
External offer Prepared Product label Prepared
Model Number
YY-25AB

Product Description Product parameter: model YYT-15AB YYT-25AB YYT-30AB Power supply Single phase 220V50HZ 380V50HZ 380V50HZ Operating voltage range 180V-250V 340-430V 340-430V Output Power 15KW 25KW 30KW Oscillation frequency 30-100KHZ 30-80KHZ 30-80KHZ

Product Description
Product parameter:
model
YYT-15AB
YYT-25AB
YYT-30AB
Power supply
Single phase 220V50HZ
380V50HZ
380V50HZ
Operating voltage range
180V-250V
340-430V
340-430V
Output Power
15KW
25KW
30KW
Oscillation frequency
30-100KHZ
30-80KHZ
30-80KHZ
Output current
200-600A
200-1200A
300-1500A
Cooling water
0.06-0.12MPa, 7. 5L/Min
0.06-0.12MPa, 7. 5L/Min
0. 08-0.16MPa, 7. 6L/Min
Water temperature protection point
40°C
40°C
40°C
Dimensions
Main: 530*225*450mm
Main: 550*225*480mm
Main: 640*260*520mm
Points: 370*210*370mm
Minute: 350*215*380mm
Minute: 440*260*410mm
weight
Main: 18kg
Main: 21.5kg
Main: 26.5kg
Minutes: 15kg
Minutes: 17kg
Points: 20.5
