Product Overview JIMTEC JITAI6103 Digital Electronic Dry Film Paint Coating Thickness Gauge for car With different probe: it can measure the thickness of non-magnetic coating layers covered on magnetic substrate. Such as: non-magnetic (aluminum, chrome, c

Product Overview
JIMTEC JITAI6103 Digital Electronic Dry Film Paint Coating Thickness Gauge for car
With different probe: it can measure the thickness of non-magnetic coating layers covered on magnetic substrate. Such as: non-magnetic (aluminum, chrome, copper, enamel, rubber, paint) covered on magnetic substrate (steel, alloy and magnetic stainless steel)
It also can measure the thickness of non-conductive coatings layers covered on conductive substrate. Such as: (enamel, rubber,paint, vanish, plastic anodic-oxide layer) covered on conductive substrate (aluminum, brass, zinc and nonmagnetic stainless steel).
PRODUCT SPECIFICATIONS
Model
JITAI6103
Measuring range
0-1250μm, depends on probes, MAX 10mm for the probe F10.
Working principle
Magnetic & Eddy
Substrate
FE / NFE base
Resolution
0.1μm
Display
128x64 LCD with backlight
Accuracy
±2%H+1um Note: H is thickness reading
Memory
5 files x 100 values
Unit switch
Metric (μm) Imperial (mil)
Working temperature
Operation Temp. : -10~50°C Storage Temp. :-30~70°C
Power
AA battery 2pcs
Weight
340g
Size
115*67*31mm
PRODUCT CONFIGURATION
Name
QTY
1
Main unit
1
2
Probe (Fe or NFe)
1
3
Calibration piece + Zeroing plate
5+1
4
Operating manual
1
5
Warranty card
1
6
Instrument case
1
